Building a Paymaster Proxy

This guide shows how to build a backend proxy for your CDP Paymaster endpoint. A proxy keeps your API key secure while allowing you to add custom validation logic for sponsored transactions.

Why Use a Proxy?

Your CDP Paymaster endpoint URL contains your Client API Key (not a Secret API Key). While this isn’t as sensitive as a secret key, exposing it in client-side code allows anyone to use your Paymaster endpoint to sponsor transactions—potentially draining your gas credits or abusing your allowlisted contracts. A proxy solves this by:

Keeping your API key server-side — The Paymaster URL never reaches the browser
Enabling custom validation — Add rate limiting, user authentication, or business logic
Providing an audit trail — Log all sponsorship requests for monitoring

For a deeper dive into security considerations, see the Security page.

When is a proxy optional?If you’re using CDP Embedded Wallets with useCdpPaymaster: true, the SDK handles paymaster communication securely. A custom proxy is only needed if you want additional validation beyond CDP’s built-in contract allowlists.

Basic Proxy Implementation

Here’s a minimal Next.js API route that proxies requests to your CDP Paymaster:

app/api/paymaster/route.ts

import { NextRequest, NextResponse } from "next/server";

const PAYMASTER_URL = process.env.CDP_PAYMASTER_URL!;

export async function POST(request: NextRequest) {
  try {
    const body = await request.json();

    const response = await fetch(PAYMASTER_URL, {
      method: "POST",
      headers: { "Content-Type": "application/json" },
      body: JSON.stringify(body),
    });

    const data = await response.json();
    return NextResponse.json(data, { status: response.status });
  } catch (error) {
    console.error("Paymaster proxy error:", error);
    return NextResponse.json(
      { error: "Internal server error" },
      { status: 500 }
    );
  }
}

Store your Paymaster URL in an environment variable (server-side only):

.env

# Never prefix with NEXT_PUBLIC_ — this must stay server-side
CDP_PAYMASTER_URL=https://api.developer.coinbase.com/rpc/v1/base-sepolia/YOUR_API_KEY

Using the Proxy

With CDP Embedded Wallets

Pass your proxy URL to useSendUserOperation:

import { useSendUserOperation } from "@coinbase/cdp-hooks";

const { sendUserOperation } = useSendUserOperation();

await sendUserOperation({
  evmSmartAccount: smartAccount,
  network: "base-sepolia",
  calls: [{ to: contractAddress, value: 0n, data: callData }],
  paymasterUrl: "/api/paymaster", // Your proxy endpoint
});

With Wagmi

Pass your proxy URL in the paymaster capabilities:

import { useWriteContracts, useCapabilities } from "wagmi/experimental";

const { data: capabilities } = useCapabilities({ account: address });

const paymasterCapabilities = useMemo(() => {
  if (capabilities?.[chainId]?.paymasterService?.supported) {
    return {
      paymasterService: {
        url: "/api/paymaster", // Your proxy endpoint
      },
    };
  }
  return {};
}, [capabilities, chainId]);

writeContracts({
  contracts: [/* your contract calls */],
  capabilities: paymasterCapabilities,
});

Adding Custom Validation

The power of a proxy is adding validation logic beyond what CDP’s allowlists provide.

Rate Limiting

Prevent abuse by limiting requests per user:

app/api/paymaster/route.ts

import { NextRequest, NextResponse } from "next/server";
import { Ratelimit } from "@upstash/ratelimit";
import { Redis } from "@upstash/redis";

const PAYMASTER_URL = process.env.CDP_PAYMASTER_URL!;

// Configure rate limiter (e.g., 10 requests per minute per IP)
const ratelimit = new Ratelimit({
  redis: Redis.fromEnv(),
  limiter: Ratelimit.slidingWindow(10, "1 m"),
});

export async function POST(request: NextRequest) {
  // Get client identifier (IP or authenticated user ID)
  const identifier = request.ip ?? request.headers.get("x-forwarded-for") ?? "anonymous";

  // Check rate limit
  const { success, remaining } = await ratelimit.limit(identifier);
  if (!success) {
    return NextResponse.json(
      { error: "Rate limit exceeded" },
      { status: 429 }
    );
  }

  const body = await request.json();

  const response = await fetch(PAYMASTER_URL, {
    method: "POST",
    headers: { "Content-Type": "application/json" },
    body: JSON.stringify(body),
  });

  const data = await response.json();
  return NextResponse.json(data, {
    status: response.status,
    headers: { "X-RateLimit-Remaining": remaining.toString() },
  });
}

User Authentication

Only sponsor transactions for authenticated users:

app/api/paymaster/route.ts

import { NextRequest, NextResponse } from "next/server";
import { getServerSession } from "next-auth";

const PAYMASTER_URL = process.env.CDP_PAYMASTER_URL!;

export async function POST(request: NextRequest) {
  // Verify user is authenticated
  const session = await getServerSession();
  if (!session?.user) {
    return NextResponse.json(
      { error: "Authentication required" },
      { status: 401 }
    );
  }

  const body = await request.json();

  // Optional: Log sponsorship request
  console.log(`Sponsoring transaction for user: ${session.user.email}`);

  const response = await fetch(PAYMASTER_URL, {
    method: "POST",
    headers: { "Content-Type": "application/json" },
    body: JSON.stringify(body),
  });

  const data = await response.json();
  return NextResponse.json(data, { status: response.status });
}

Custom Business Logic

Add application-specific rules:

app/api/paymaster/route.ts

import { NextRequest, NextResponse } from "next/server";

const PAYMASTER_URL = process.env.CDP_PAYMASTER_URL!;

// Example: Maximum sponsorship per user per day
const dailyLimits = new Map<string, number>();

export async function POST(request: NextRequest) {
  const session = await getServerSession();
  if (!session?.user?.id) {
    return NextResponse.json({ error: "Unauthorized" }, { status: 401 });
  }

  const userId = session.user.id;
  const todayKey = `${userId}-${new Date().toDateString()}`;
  const currentCount = dailyLimits.get(todayKey) ?? 0;

  // Limit to 5 sponsored transactions per day per user
  if (currentCount >= 5) {
    return NextResponse.json(
      { error: "Daily sponsorship limit reached" },
      { status: 403 }
    );
  }

  const body = await request.json();

  const response = await fetch(PAYMASTER_URL, {
    method: "POST",
    headers: { "Content-Type": "application/json" },
    body: JSON.stringify(body),
  });

  if (response.ok) {
    dailyLimits.set(todayKey, currentCount + 1);
  }

  const data = await response.json();
  return NextResponse.json(data, { status: response.status });
}

For production, store rate limits and usage counts in a persistent store like Redis rather than in-memory.

Express.js Example

If you’re not using Next.js, here’s an Express equivalent:

server.ts

import express from "express";
import cors from "cors";

const app = express();
app.use(cors());
app.use(express.json());

const PAYMASTER_URL = process.env.CDP_PAYMASTER_URL!;

app.post("/api/paymaster", async (req, res) => {
  try {
    const response = await fetch(PAYMASTER_URL, {
      method: "POST",
      headers: { "Content-Type": "application/json" },
      body: JSON.stringify(req.body),
    });

    const data = await response.json();
    res.status(response.status).json(data);
  } catch (error) {
    console.error("Paymaster proxy error:", error);
    res.status(500).json({ error: "Internal server error" });
  }
});

app.listen(3001, () => {
  console.log("Paymaster proxy running on port 3001");
});

Testing Your Proxy

Local Development

For local development, you can temporarily use the Paymaster URL directly in your frontend to verify your smart account setup works. Once confirmed, switch to your proxy.

Verify the Proxy Works

Start your backend server
Send a test request to your proxy endpoint:

curl -X POST http://localhost:3000/api/paymaster \
  -H "Content-Type: application/json" \
  -d '{"jsonrpc":"2.0","id":1,"method":"pm_getPaymasterStubData","params":[{},{},"0x5FF137D4b0FDCD49DcA30c7CF57E578a026d2789","84532"]}'

You should receive a JSON-RPC response (either success or an error about invalid params—both confirm the proxy is forwarding correctly)

Production Checklist

Before deploying:

Environment variable is server-side only — No NEXT_PUBLIC_ prefix
Rate limiting configured — Prevent abuse
Authentication required — Only sponsor for your users
Error handling — Graceful failures with appropriate status codes
Logging — Monitor sponsorship requests and failures
Contract allowlist configured — Set up in CDP Portal as a secondary defense

Next Steps

Security — Full security recommendations
Errors — Common error codes and solutions
Troubleshooting — Debugging failed transactions
